Mixing capacity 1,2)

6,0 - 14,0

m³/h

Density wet 1,2)

approx. 200 - 700

kg/m³

reachable exactness 1)

+/- 3

%

Dry density foam concrete

approx. 150 - 600

kg/m³

Tolerances green mortar density 2)

+/- 5

%

Output foam generator

60 - 150

l/min; adjustable

Foam density

 40 - 80

kg/m³; adjustable

Foaming agent rate

0,5 - 4,0

%; adjustable

Water consumption

max. 20

l/min

Water connection (external)

DN 20

GEKA claw-coupling

Connection transport hose

(foam concrete)

Storz C

2 “  standard coupling DIN14307

Length transport hose

max. 60

m; longer lengths on request / possible after technical clarification

Power connection

CEE-plug

32 A, 5- pole with phase inverter

Power input

max. 9,0

kW

Voltage

415

V; 50 Hz

Transport dimensions

2,2 x 1,1 x 2,0

m ( L x W x H)

Weight

 470

kg
