Products

Mixing capacity (25 batches/h)

(w/s ratio 1.0)

approx. 12.5

m³/h

Effective mixer volume

500

l

Mixing water minimum

170

l

Water tank volume

450

l

Buffer tank volume

1500

l

Flow rate

0 – 210

l/min, electrically continuously adjustable

Discharge pressure

approx. max. 100

bar, electrically continuously limited

Grain size

max. 2

mm

Pressure connection

1 1/2 “

IG

Amount mixing components

3

1 liquid

2 x solid

Water connection

Storz B

2 ½ “standard coupling DIN14307

Cleaning connection

DN 25

Geka claw coupling

Power connection

CEE-plug

2 x 63 A, 5-pole

Power input

approx. 42

KW

Voltage

400

V; 50 Hz

Dimensions

2,81 x 2,25 x 2,30

m (L x B x H)

Weight

 approx. 2900

kg
