CMA-250-EAC

◀
▶

Technical Data / Performance Data

Mixing capacity (with 15 batches/h)

3,75

m3/h

Effective volume mixer

 80 - 250

l

Mixing water minimum

80

l

Effective volume agitator tank

500

l

Flow rate dosing pump

20 - 100

l/min   infinitely adjustable

Discharge pressure dosing pump

max. 30

bar

Mixing components

2

1 liquid

1 solids

Solids grain size

 max. 2

mm

Pressure connection slurry pump

1“

IT outer container wall

Water connection

2"

IT outer container wall

Power connection

CEE-plug

63 A, 5-pole

Power input

approx. 26

kW

Voltage

400

V, 50 Hz

Transport / Mixer work dimensions

6,0 x 2,44 x 2,9

m ( L x W x H)

Weight

approx. 4830

kg



Application areas:

  • Anchor injection
  • Grouting
  • Drilling fluid
  • Cavity filling
  • micro tunneling
  • Ground injection
  • Bentonite lubrication
  • next.beton

Characteristics:

  • processing of bagged goods or silo goods (bagged goods with manual sack loading)
  • the flow rate of the dosing pump is infinitely adjustable
  • easy operation, maintenance and cleaning
  • minimum mounting and start-up effort
  • optimal mixing quality (colloidal mixer)
  • minimum space requirements
  • minimum operating costs
